Seiko H2 74S
Description:
Gepflegter Drucker aus Mitte 2013
mit nur 21000 m2 abtzugeben wegen
Umstieg auf Seiko in 2,6m !!
2 Generation der Seiko HS 74.
Schnell und günstig im Druck
Neupreis 41000,-
Specifications
Model IP-7900-20
(ColorPainter H2-74s)
Print Head High-frequency drop on demand piezo
Number of Nozzles 508 nozzles × 8
Resolution 360 dpi to 900 dpi
Maximum Print Width1,890 mm (74.4")
Media Weight Up to 120 kg (264 lbs.) Up to 50 kg (110 lbs.)
Maximum Media Diameter 350 mm (13.8") 220 mm (8.7")
Margin Size 5 mm on each edge (with rolled media, without edge guards)
Ink Type Mild Solvent : EGO-GX
Color 8 (C, M, Y, K, Lc, Lm, Gray & Light Gray) or 4 (C, M, Y, K) × 2
Ink Capacity 1,500 ml per color
Media PVC, banner and other media designed for solvent printers.
Heater 3-way built in heaters (Front/Print/Rear); Max temp. 70 ºC
Take-up modes Loose/Inner, Loose/Outer, Tension/Inner, Tension/Outer
Interface USB 2.0
Power Voltage 200 to 240 VAC, ±10%
Power Consumption Printer: 1440 W or less, Heater: 2880 W or less
Operating Environment 15 - 30ºC (59 - 86ºF ), 30 to 70% RH (no condensation)
Storage Environment 5 - 35ºC (41 - 95ºF), 10 to 80% RH (no condensation)
External Dimensions
(W) x (D) x (H) 4126 × 1366 × 1513 mm
(162" × 54" × 60") 3,383 × 1,275 × 1,511 mm
(133" × 50" × 60”)
Weight 600 kg (1,322 lbs.) or less 450 kg (992 lbs.) or less
Option Mesh Printing Kit, Foot Switch, Scroller, Exhaust Attachments, Scroller Set (Shaft & 2 Flanges), Scroller Flange
